The most professional of the micro-tractors

The versatile TAFE 6028M stands out from its class due to its technical features. Its compact design combined with good performance make it a versatile product for a variety of functions in private and commercial use.

1318 cc 24.6 hp at 2600 rpm

Mitsubishi 25hp engine

25 km/h

Maximum speed

739 KG lifting capacity

on the rear lift

1 / 3
Follow us on our YouTube channel

ITS STRENGTHS

EU STAGE V engine

The 3-cylinder diesel engine in the TAFE 6028 M complies with EU STAGE 5 legislation, in line with the global initiative to reduce the environmental impact of internal combustion engines.

Transmission system 9F + 3R

The transmission configuration of the TAFE 6028 M compact tractor offers excellent speed in a wide range of operations. Its transmission configuration offers a perfect balance between forward speed and reverse manoeuvring capability in tight spaces.

Dual-speed power take-off (PTO)

The TAFE 6028 M is equipped with a dual-speed power take-off (PTO), capable of operating both high and low-speed implements. This feature multiplies its range of action in various applications.

Lifting capacity

With a lifting capacity of an impressive 739 kg, the TAFE 6028 M is optimised for high-performance integration with a myriad of equipment. This design, supported by advanced mechanical engineering, ensures maximum precision in a variety of applications.

Multiple tyre options

Designed to be versatile, TAFE tractors offer a wide range of tyres suitable for any terrain and task, ensuring optimal traction, durability and performance according to use and specific needs.

Standard

TAFE 6028 M

The TAFE 6028M stands out from its class due to its technical strengths. Its compact design combined with good performance makes it a versatile tool for a variety of tasks in private and commercial use.

Farm Tractor TAFE 6028M - Standard agricultural tyres - Italian road homologation.

TAFE 6028M

Specifications

Engine and transmission

CV
24 @ 2600 rpm
N° Cylinders
3
Power - Maximum torque
76 Nm @ 2000 rpm.
Displacement
1318 cc
battery
12 V
Type of gearbox
Always in the grip
Marches
9A + 3R
Steering
Servo-assisted
Maximum speed
25 km/h
Air filter
Dry

Dimensions

Ground clearance
260 mm
Pass
1550 mm
Total weight
1095 kg

HYDRAULIC SYSTEM

Lifting capacity
739 kg
Pump
Gear pump
Hydraulic control
Automatic depth and effort control

Brakes

Type
Oil immersed brakes

PTO

PTO
Power take-off with 2 speeds 540 and 750 rpm.

FURNISHING

Bonnet
Opening
headlights
LED headlights
Seating
With retractable seat belt
Other features
Stationary PTO
